F-2301 PVC HOSE Embedded galvanized steel spiral for suction, delivery of food, food oils
The surface of hose is smooth and sofe, Resistant chemical substances Table PU, no phthalate. US FDA 21 CFR 177.2600, EU EC 193/2004
หมวดหมู่ :
Food & Chemical Hoses
รายละเอียดสินค้า
F-2301 PVC HOSE
Application: PVC hose embedded galvanized steel spiral for suction, delivery of food, food oils
Technical Description : The surface of hose is smooth and sofe, Resistant chemical substances Table PU, no phthalate.
Temperature Range :
From 15° C to +65°C
Standard/Approval : Complies with EU EC 193/2004, US FDA 21 CFR 177.2600
| Size(inc.) | Internal diameter. (mm.) | External diameter. (mm.) | Working Pressure (bar) | Burst pressure (bar) | Vacuum (bar) | Min Bending Radius(mm) | Appros Weight (kg/mm) | Max Length(mm) |
| 3/8" | 10.0 | 16.2 | 7.0 | 21.0 | 0.9 | 30.0 | 0.2 | 50 |
| 5/8" | 16.0 | 22.2 | 7.0 | 21.0 | 0.9 | 48.0 | 0.2 | 50 |
| 3/4" | 19.0 | 26.2 | 7.0 | 21.0 | 0.9 | 57.0 | 0.3 | 50 |
| 1" | 25.3 | 33.5 | 7.0 | 18.0 | 0.9 | 75.0 | 0.5 | 50 |
| 1-1/4" | 32.0 | 40.0 | 6.0 | 18.0 | 0.9 | 96.0 | 0.6 | 50 |
| 1-1/2 | 38.0 | 47.0 | 6.0 | 18.0 | 0.9 | 114.0 | 0.8 | 50 |
| 2" | 51.0 | 62.0 | 6.0 | 18.0 | 0.9 | 150.0 | 1.3 | 50 |
| 2-1/2" | 63.5 | 75.0 | 5.0 | 15.0 | 0.9 | 180.0 | 1.9 | 50 |
| 3" | 76.0 | 88.0 | 5.0 | 15.0 | 0.9 | 225.0 | 2.2 | 50 |
| 4" | 102.0 | 119.0 | 3.0 | 9.0 | 0.9 | 306.0 | 3.6 | 50 |
