F-0041 PTFE Hose with light weight, Universal hose high tenacity & low friction factor
Smooth linner, easy to be cleaned and drained. Suitable for deliverying viscous product which require dynamic hygienic applications.
หมวดหมู่ :
Food & Chemical Hoses
รายละเอียดสินค้า
F-0041 PTFE HOSES
Application: Universal hose with high tenacity and low friction factor to convey a wide variety of phamaceutical, cosmetic and food products within the phama-cosmetic, biotech and food industries.
Features:
PTFE hose with ligh weight, smooth linner, easy to be cleaned and drained. The hose has excellent resistance to high pressure and temperature, remains favourable pressure resistance even at high temperature. Suitable for deliverying viscous product which require dynamic hygienic applications.
Technical Description : Standard and antistatic in-linner alternative Tube : Smooth Teflon Cover: SS304 Stainless steel braid.
Temperature Range :
From -70° C to +260° C
Standard/Approval : FDA 21 CFR 177.2600 Quality Standard
| No. | Size(inc.) | Internal diameter. (mm.) | External diameter. (mm.) | Working Pressure (bar) | Burst Pressure (bar) | Min Bending Radius(mm) | Appros Weight (kg/mm) |
| 1 | 1/8" | 3.2 | 6.50 | 1 | 276 | 828 | 0.08 |
| 2 | 3/16" | 5.0 | 7.70 | 0.85 | 264 | 793 | 0.09 |
| 3 | 1/4" | 6.0 | 8.70 | 0.85 | 224 | 672 | 0.093 |
| 4 | 5/16" | 8.0 | 11.30 | 0.85 | 207 | 552 | 0.141 |
| 5 | 3/8" | 10.0 | 13.20 | 0.85 | 183 | 483 | 0.148 |
| 6 | 1/2" | 12.7 | 16.50 | 1 | 161 | 345 | 0.249 |
| 7 | 5/8" | 15.9 | 19.50 | 1 | 114 | 310 | 0.29 |
| 8 | 3/4" | 19.0 | 23.00 | 1.2 | 103 | 276 | 0.339 |
| 9 | 7/8" | 22.2 | 26.20 | 1.2 | 92 | 241 | 0.382 |
| 10 | 1" | 25.0 | 29.50 | 1.5 | 80 | 195 | 0.461 |
