P-1164 SILIFLEX Very smooth inliner and cover good for cleaning
It is only applicable to delivety purpose, and can be used for deliverying milk, beverages, as well as purified water. good for cleaning and sterilization.
หมวดหมู่ :
Food & Chemical Hoses
รายละเอียดสินค้า
P-1164 SILIFLEX HOSES
Application: The hose has very smooth inliner and cover, which is P-1164 SILIFLEX Very smooth inliner and cover good for cleaning, as well as purified water. Not recommend for liquid suction and suction pump application.
Technical Description :
The hose is made by the platinum vulcanized silicone and 4 layers reinforded polyester fabric structure. Standard length is 6 meters or speially 10 meters. The inner wall is smooth and cleaning materials, no residue remained. The steam disinfection and sterilization can be done under high temperature and high pressure.
Temperature range : From -60 to +200° C
Standard/Approval : US Pharmacopeia Class VI-test Report; Compliance: FDA 21 CFR 177.2600 GB-4806.11-2016 GB-31604.30.
| No. | Size(inc.) | Internal diameter. (mm.) | External diameter. (mm.) | Working Pressure (bar) | Burst Pressure (bar) | Vacuum (bar) | Max Length (m) |
| 1 | 1/4" | 6 | 16 | 11.7 | 35.0 | N/A | 6 |
| 2 | 5/16" | 8 | 18 | 10.7 | 32.0 | N/A | 6 |
| 3 | 3/8" | 10 | 20 | 9.7 | 29.0 | N/A | 6 |
| 4 | 1/2" | 13 | 23 | 8.7 | 26.0 | N/A | 6 |
| 5 | 5/8" | 16 | 26 | 8.0 | 24.0 | N/A | 6 |
| 6 | 3/4" | 19 | 29 | 7.7 | 23.0 | N/A | 6 |
| 7 | 1" | 25 | 35 | 6.7 | 20.0 | N/A | 6 |
| 8 | 1-1/4" | 32 | 42 | 5.7 | 17.0 | N/A | 6 |
| 9 | 1-1/2" | 38 | 48 | 5.0 | 15.0 | N/A | 6 |
| 10 | 2" | 51 | 61 | 4.0 | 12.0 | N/A | 6 |
| 11 | 2-1/2" | 63 | 73 | 3.3 | 10.0 | N/A | 6 |
| 12 | 3" | 76 | 86 | 2.7 | 8.0 | N/A | 6 |
| 13 | 3-1/2" | 89 | 99 | 2.0 | 6.0 | N/A | 6 |
| 14 | 4" | 102 | 112 | 1.7 | 5.0 | N/A | 6 |
